24 m

Prod.No. 93731 EAN: 4007529937318 lens PD4N, Cover ring

  • Detection area: horizontal 360° (Ceiling mounting)
  • Range: max. Ø 24 m across
    max. Ø 8 m towards
    max. Ø 6.4 m seated
  • Monitored area (tangential movement): 450 m² / 2.5 m mounting height
Range
24.00 m
40.00 m
24.00 m
Colour
anthracite
white
Show available options
anthracite
traffic white black
Designation Value
Detection area: horizontal 360° (Ceiling mounting)
Range: max. Ø 24 m across
max. Ø 8 m towards
max. Ø 6.4 m seated
Monitored area (tangential movement): 450 m² / 2.5 m mounting height
Mounting height min./max./recommended: 2 m / 10 m / 2.5 m
Impact strength: IK04
Housing: polycarbonate, UV-resistant
Material color: anthracite mat, similar to RAL7016

Replacement lens with cover ring for colour matching

For usability/compatibility of the accessories please refer to the descriptions of the main articles

Suitable for: 93241, 93340, 93377, 93460, 93463, 93473, 93474, 93514, 93515, 93516, 93517, 93535, 93536, 93546, ...

Tender document 93731 Downloads
Short instruction Downloads

Alternative

24 m
anthracite
Prod.No. 93736

lens PD4N-1C, Cover ring

  • Detection area: horizontal 360° (Ceiling mounting)
  • Range: max. Ø 24 m across
    max. Ø 8 m towards
    max. Ø 6.4 m seated
  • Monitored area (tangential movement): 450 m² / 2.5 m mounting height
Go to product
24 m
black
Prod.No. 93733

lens PD4N, Cover ring

  • Detection area: horizontal 360° (Ceiling mounting)
  • Range: max. Ø 24 m across
    max. Ø 8 m towards
    max. Ø 6.4 m seated
  • Monitored area (tangential movement): 450 m² / 2.5 m mounting height
Go to product
24 m
traffic white
Prod.No. 93732

lens PD4N, Cover ring

  • Detection area: horizontal 360° (Ceiling mounting)
  • Range: max. Ø 24 m across
    max. Ø 8 m towards
    max. Ø 6.4 m seated
  • Monitored area (tangential movement): 450 m² / 2.5 m mounting height
Go to product
