10 m

Prod.No. 92550 EAN: 4007529925506 PD2-M-1C-SM

  • Voltage: 110 – 240 V AC 50 / 60 Hz
  • Dimensions: SM= Ø 98 x 47 mm
  • Power consumption: approx. 0.4 W
Mounting
surface-mounted
surface-mounted
flush-mounted ceiling-mounted
Channel
1
2
1
Designation Value
Voltage: 110 – 240 V AC 50 / 60 Hz
Dimensions: SM= Ø 98 x 47 mm
Power consumption: approx. 0.4 W
Detection area: horizontal 360° (Ceiling mounting)
Range: max. Ø 10 m across
max. Ø 6 m towards
max. Ø 4 m seated
Monitored area (tangential movement): 78 m² / 2.5 m mounting height
Mounting height min./max./recommended: 2 m / 5 m / 2.5 m
Degree / class of protection: SM= IP20 / Class II
Impact strength: IK05
Ambient temperature: -25 °C to +50 °C
Housing: polycarbonate, UV-resistant
Material color: white mat, similar to RAL9010
: Channel 1 (lighting control, potential-free (dry))
Switching power: 2300 W, cos φ = 1
1150 VA, cos φ = 0.5
300 W LED
max. inrush current Ip (20 ms) = 165 A
max. inrush current Ip (200 µs) = 800 A
Type of contact (k): 1x µ-contact, dry NO contact with tungsten pre-make contact
Follow-up time: 15 sec – 30 min, Pulse
Switch-on threshold: 10 – 2000 Lux
Light measuring: Mixed light measuring

Occupancy detector with one potential-free dry contact

Version as master device

One channel for light switching

Detection area can be extended by using slave devices

Manual switching via push-button possible

Additional functions can be set up using the optional remote control.

Factory settings 10 min and 500 lux

Typical applications:
Offices, conference rooms, schools, nursery schools, hospitals
