Prod.No. 93615 EAN: 4007529936151 AL12-25-300-LED-3C

  • Voltage: 200 – 240 V AC 50 Hz
  • Dimensions: 300 x 300 x 41 mm
  • Colour temperature: 3000 / 4000 / 5700 K
Technical data sheet
  • Features
  • Description
  • Downloads
Designation Value
Voltage 200 – 240 V AC 50 Hz
Dimensions 300 x 300 x 41 mm
Colour temperature 3000 / 4000 / 5700 K
Luminous flux / intensity 2500 / 2700 / 2600 lm
Anti-glare 30
Efficiency 100 / 108 / 104 lm/W
Photobiological safety RG 0
Colour reproduction CRI > 80 / TM30: 82
Rated life time 50000 h (L80/B10)
Power consumption 25 W / PF 0.9
Degree / class of protection IP54 / Class II
Flammability rating UL-94 V2, 750 °C
Impact strength IK10
Ambient temperature -20 °C to +45 °C
Housing polycarbonate, UV-resistant
Material color white, similar to RAL9016

Flat LED light for wall or ceiling mounting

Three colours in one light, switchable selection between warm, neutral or daylight white illumination

Every colour temperature is externally dimmable

Energy efficient light with long service life > 50,000 hours

Broad light distribution using diffused light covers

Sturdy plastic case made of polycarbonate

high fire protection rating

water-protected (IP54) after installation

Simple mounting with separate mounting bracket

Application examples:
equipment rooms, corridors/hallways, staircases, toilets, entrance halls, plumbed rooms/bathrooms

Tender document 93615 Download
CE declaration of conformity 93615 (en) Download
MAN_9861_AL12-3C_ShortManual_DE-GB-FR-NL_300817.pdf Download
Information material Download
Photometric data EULUMDAT CW Download
Photometric data EULUMDAT NW Download
Photometric data EULUMDAT WW Download
